Influence of annular portion of wrapped beam on propagation of central filament

XU Hu; XU Guang; WANG Zhaoqiang; CHEN Xi; LU Chenhui

doi:10.12299/jsues.24-0075

Volume 39 Issue 2

Jun. 2025

Turn off MathJax

Article Contents

Article Navigation > Journal of Shanghai University of Engineering Science > 2025 > 39(2): 229-235

XU Hu, XU Guang, WANG Zhaoqiang, CHEN Xi, LU Chenhui. Influence of annular portion of wrapped beam on propagation of central filament[J]. Journal of Shanghai University of Engineering Science, 2025, 39(2): 229-235. doi: 10.12299/jsues.24-0075

Citation:

XU Hu, XU Guang, WANG Zhaoqiang, CHEN Xi, LU Chenhui. Influence of annular portion of wrapped beam on propagation of central filament[J]. Journal of Shanghai University of Engineering Science, 2025, 39(2): 229-235. doi: 10.12299/jsues.24-0075

Citation:

PDF( 2080 KB)

Influence of annular portion of wrapped beam on propagation of central filament

doi: 10.12299/jsues.24-0075

School of Mechanical and Automotive Engineering, Shanghai University of Engineering Science, Shanghai 201620, China

Received Date: 2024-03-18
Available Online: 2025-09-30
Publish Date: 2025-06-30

Abstract

Abstract

Light filaments are pivotal in ultrafast laser applications, and enhancing the long-distance propagation of light filaments substantially broadens their application prospects.Wrapped beams exhibits characteristics that significantly enhance the long-distance propagation of light filaments, with their annular portions playing a crucial role during propagation. Based on the split-step Fourier transform simulation method, the propagation characteristics of wrapped beams endowed with varied annular segments were systematically investigated through comparative simulation. The results indicate that the input energy, beam waist radius and central distance of the annular portion of the wrapped beam all influence the filament's propagation. Fine-tuning the annular parameters can optimize the propagation efficiency of laser filamentation, expanding the applications domains of ultrafast lasers.
- femtosecond laser filamentation,
- nonlinear propagation,
- multiphoton ionisation,
- split-step Fourier method,
- wrapped beam

FullText(HTML)

References(18)

References

[1]	BRAUN A, KORN G, LIU X, et al. Self-channeling of high-peak-power femtosecond laser pulses in air[J] . Optics Letters, 1995, 20(1): 73 − 75. doi: 10.1364/OL.20.000073
[2]	HOUARD A, WALCH P, PRODUIT T, et al. Laser-guided lightning[J] . Nature Photonics, 2023, 17(3): 231 − 235. doi: 10.1038/s41566-022-01139-z
[3]	PRODUIT T, WALCH P, HERKOMMER C, et al. The laser lightning rod project[J] . The European Physical Journal Applied Physics, 2021, 93(1): 10504. doi: 10.1051/epjap/2020200243
[4]	YUN Q J, SONG B F, PEI Y. Modeling the impact of high energy laser weapon on the mission effectiveness of unmanned combat aerial vehicles[J] . IEEE Access, 2020, 8: 32246 − 32257. doi: 10.1109/ACCESS.2020.2973492
[5]	AHMED S A, MOHSIN M, ALI S M Z. Survey and technological analysis of laser and its defense applications[J] . Defence Technology, 2021, 17(2): 583 − 592. doi: 10.1016/j.dt.2020.02.012
[6]	RAČIUKAITIS G. Ultra-short pulse lasers for microfabrication: a review[J] . IEEE Journal of Selected Topics in Quantum Electronics, 2021, 27(6): 1100112.
[7]	LUTZ C, ROTH G L, RUNG S, et al. Efficient ultrashort pulsed laser processing by dynamic spatial light modulator beam shaping for industrial use[J] . Journal of Laser Micro/Nanoengineering, 2021, 16(1): 62 − 67.
[8]	SUN W F, WANG X K, ZHANG Y. Terahertz generation from laser-induced plasma[J] . Opto-Electronic Science, 2022, 1(8): 220003. doi: 10.29026/oes.2022.220003
[9]	OH T I, YOU Y S, JHAJJ N, et al. Intense terahertz generation in two-color laser filamentation: energy scaling with terawatt laser systems[J] . New Journal of Physics, 2013, 15(7): 075002. doi: 10.1088/1367-2630/15/7/075002
[10]	IONIN A A, KUDRYASHOV S I, MAKAROV S V, et al. Multiple filamentation of intense femtosecond laser pulses in air[J] . JETP Letters, 2009, 90(6): 423 − 427. doi: 10.1134/S0021364009180040
[11]	MÉCHAIN G, COUAIRON A, ANDRÉ Y B, et al. Long-range self-channeling of infrared laser pulses in air: a new propagation regime without ionization[J] . Applied Physics B, 2004, 79(3): 379 − 382. doi: 10.1007/s00340-004-1557-8
[12]	POLYNKIN P, KOLESIK M, ROBERTS A, et al. Generation of extended plasma channels in air using femtosecond Bessel beams[J] . Optics Express, 2008, 16(20): 15733 − 15740. doi: 10.1364/OE.16.015733
[13]	MILLS M S, KOLESIK M, CHRISTODOULIDES D N. Dressed optical filaments[J] . Optics Letters, 2013, 38(1): 25 − 27. doi: 10.1364/OL.38.000025
[14]	马存良, 嘉明珍, 林文斌. 不同能量下环形高斯强激光光束在空气中的非线性传输[J] . 强激光与粒子束, 2016, 28(8): 081001. doi: 10.11884/HPLPB201628.151290
[15]	MA C L, JIA M Z, LIN W B, et al. Extending optical filaments of annular beams via square root spatial phase modulation[J] . Optics Communications, 2020, 458: 124828. doi: 10.1016/j.optcom.2019.124828
[16]	LÜ J Q, CHENG T Y, WANG W Y, et al. Analysis of the extension of optical filament in air based on phase-nested laser beam[J] . Optics Communications, 2022, 519: 128244. doi: 10.1016/j.optcom.2022.128244
[17]	COUAIRON A, MYSYROWICZ A. Femtosecond filamentation in transparent media[J] . Physics Reports, 2007, 441(2/4): 47 − 189.
[18]	BÉJOT P, KASPARIAN J, HENIN S, et al. Higher-order Kerr terms allow ionization-free filamentation in gases[J] . Physical Review Letters, 2010, 104(10): 103903. doi: 10.1103/PhysRevLett.104.103903
