Global frequency synchronization of complex power networks based on cooperative control
-
摘要: 研究复杂电力网络的全局渐近频率同步问题，提出一种新的协同控制策略。该策略同时在发电机侧和负载侧控制，实现了复杂电力网络的全局频率同步。与传统的线性化方法相比，所提出的协同控制策略解除了母线电压相位差不超过$0.5{\text{π}} $的限制。这表明，对于任意母线电压相位差，复杂电力网络都可以实现渐近频率同步，拓展了系统的应用场景。根据Lyapunov稳定性理论，得到复杂电力网络实现全局渐近频率同步的充分条件。最后，仿真结果表明本研究所得结果是正确的和有效的。Abstract: The problem of global asymptotic frequency synchronization for complex power networks was investigated, and a novel cooperative control strategy was proposed. The strategy simultaneously controlled both the generator and load sides, and achieved global frequency synchronization in complex power networks. Compared with the traditional linearization methods, the restriction that the bus voltage phase difference must not exceed $0.5{\text{π}} $ was eliminated by the proposed cooperative control strategy. This indicates that asymptotic frequency synchronization can be achieved for complex power networks with any bus voltage phase difference, which expands the system's application scenarios. In addition, based on Lyapunov stability theory, sufficient conditions for the complex power network to achieve global asymptotic frequency synchronization were derived. Finally, the simulation results demonstrate that the proposed method is correct and effective.
-
表 1 系统相关参数
Table 1. System related parameters
参数 i = 1 i = 2 i = 3 i = 4 i = 5 i = 6 ${D_i}$ 1.16 0.46 3.57 1 1 1 ${f_i}$ 88 76 111 — — — ${M_i}$ 1 2 3 4 5 6 ${\theta _i}$ 2 5 −3 2.4 1 2 ${\omega _i}$ 40 30 50 — — — ${P_D}_{_i}$ — — — 0.55 0.13 0.72
下载: 导出CSV
-
[1] CHALAKI B, MALIKOPOULOS A A. Time-optimal coordination for connected and automated vehicles at adjacent intersections[J] . IEEE Transactions on Intelligent Transportation Systems, 2022, 23(8): 13330 − 13345. doi: 10.1109/TITS.2021.3123479 [2] 王柯杰, 童东兵, 陈巧玉, 等. 参数不确定永磁同步电机的固定时间同步研究[J] . 上海工程技术大学学报, 2023, 37(3): 228 − 232. doi: 10.3969/j.issn.1009-444X.2023.03.003 [3] HOU S C, CHEN J W, CHEN G. Distributed control strategy for voltage and frequency restoration and accurate reactive power-sharing for islanded microgrid[J] . Energy Reports, 2023, 9: 742 − 751. [4] SAADAT H. Power system analysis[M] . Boston: McGraw-Hill, 1999. [5] ULBIG A, BORSCHE T S, ANDERSSON G. Impact of low rotational inertia on power system stability and operation[J] . IFAC Proceedings Volumes, 2014, 47(3): 7290 − 7297. doi: 10.3182/20140824-6-ZA-1003.02615 [6] GUERRERO J M, VASQUEZ J C, MATAS J, et al. Hierarchical control of droop-controlled AC and DC microgrids: a general approach toward standardization[J] . IEEE Transactions on Industrial Electronics, 2011, 58(1): 158 − 172. doi: 10.1109/TIE.2010.2066534 [7] 张中超, 邹晓明, 翟献超, 等. 考虑负载均衡度的供电网负荷自动均衡调度系统[J] . 自动化技术与应用, 2024, 43(7): 89 − 92,106. doi: 10.20033/j.1003-7241.(2024)07-0089-05 [8] RANJAN M, SHANKAR R. A literature survey on load frequency control considering renewable energy integration in power system: recent trends and future prospects[J] . Journal of Energy Storage, 2022, 45: 103717. doi: 10.1016/j.est.2021.103717 [9] MALLADA E, ZHAO C H, LOW S. Optimal load-side control for frequency regulation in smart grids[J] . IEEE Transactions on Automatic Control, 2017, 62(12): 6294 − 6309. doi: 10.1109/TAC.2017.2713529 [10] TIAN E G, PENG C. Memory-based event-triggering H∞ load frequency control for power systems under deception attacks[J] . IEEE Transactions on Cybernetics, 2020, 50(11): 4610 − 4618. doi: 10.1109/TCYB.2020.2972384 [11] JIA Y B, MENG K, WU K, et al. Optimal load frequency control for networked power systems based on distributed economic MPC[J] . IEEE Transactions on Systems, Man, and Cybernetics: Systems, 2021, 51(4): 2123 − 2133. doi: 10.1109/TSMC.2020.3019444 [12] 李世涛, 张鑫堯. 基于改进粒子滤波的微电网频率自适应控制方法研究[J] . 自动化仪表, 2024, 45(5): 118 − 122,126. doi: 10.16086/j.cnki.issn1000-0380.2023050077 [13] 刘勇, 刘斌, 傅志忠, 等. 时滞孤岛微电网负荷频率控制系统在采样控制下的指数稳定[J] . 电力科学与工程, 2024, 40(5): 1 − 8. doi: 10.3969/j.ISSN.1672-0792.2024.05.001 [14] LIU T, HILL D J, ZHANG C C. Non-disruptive load-side control for frequency regulation in power systems[J] . IEEE Transactions on Smart Grid, 2016, 7(4): 2142 − 2153. doi: 10.1109/TSG.2016.2538287 [15] LOMBANA D A B, DI BERNARDO M. Multiplex PI control for consensus in networks of heterogeneous linear agents[J] . Automatica, 2016, 67: 310 − 320. doi: 10.1016/j.automatica.2016.01.039 [16] BERGEN A R, HILL D J. A structure preserving model for power system stability analysis[J] . IEEE Transactions on Power Apparatus and Systems, 1981, PAS-100(1): 25−35. [17] 曹晓, 李泽, 崔国增. 孤岛微电网固定时间分布式鲁棒二次控制[J] . 电力系统保护与控制, 2024, 52(12): 143 − 153. doi: 10.19783/j.cnki.pspc.231420 [18] SUN J, LIU J, WANG Y D, et al. Fixed-time event-triggered synchronization of a multilayer Kuramoto-oscillator network[J] . Neurocomputing, 2020, 379: 214 − 226. doi: 10.1016/j.neucom.2019.10.040 [19] WU J, YU X H, LI X. Global frequency synchronization of complex power networks via coordinating switching control[J] . IEEE Transactions on Circuits and Systems I: Regular Papers, 2019, 66(8): 3123 − 3133. doi: 10.1109/TCSI.2019.2908085 -
下载:
点击查看大图
图(1) / 表(1)
